Jagdpanzer 38(t) Hetzer .STL 1/10
The Jagdpanzer 38(t) Hetzer was a German tank destroyer introduced during World War II. It was built on the chassis of the Czechoslovak light tank LT vz. 38, which speaks to the quality of the original design. The Hetzer (German for “baiter” or “chased one”) was designed as a cheaper, more compact, and easier-to-produce alternative to larger and more complex German tank destroyers. Thanks to its low silhouette and sloped armor, it was hard to hit and well-protected despite its relatively light weight and small size.
The tank destroyer was armed with a 75 mm PaK 39 gun, capable of dealing with most Allied armored vehicles. It was crewed by four men – driver, gunner, loader, and commander. The vehicle stood out for its simplicity, reliability, and low maintenance, making it ideal for mass production and deployment in field conditions.
The Hetzer saw action on both the Eastern and Western fronts and was also used post-war – for example, by the Swiss army. Today, it remains one of the iconic armored vehicles of its era and a popular model among collectors and hobbyists.
The 1:10 scale tank kit is primarily designed for remote control. However, it can also be used as a static display piece. STL files are designed for detailed and realistic construction, catering to military technology enthusiasts. The model’s chassis features realistic leaf spring suspension, inspired by the original vehicle. The structure is designed for modular assembly – most components are connected with screws and glue, ensuring high structural strength. The upper hull is easily detachable for convenient access to electronics, easy maintenance, and simplified repairs.
The model can optionally be enhanced with a variety of features – such as airsoft mechanics, gun recoil, a functional exhaust with smoke effect, or a sound module. The print files are optimized for home 3D printers, focusing on easy printing and assembly.
Main Features of the Jagdpanzer 38(t) Hetzer Tank Destroyer Kit:
- scale: 1:10
- high-detail design 1)
- high-quality and very strong construction
- easy removal of the upper tank section for quick access to internal electronics
- simple assembly using a system of locks and screws
- quiet and powerful belt-driven hybrid gearboxes
- leaf spring suspension chassis, just like the real vehicle
- gun recoil (optional)
- easy chassis maintenance
- fully disassemblable chassis – easy to replace bearings without reprinting the entire assembly
- separate wheels and rubber tires that can be easily replaced when worn
- simple leaf spring replacement without removing tracks or wheels
- rubber tires for the road wheels can be printed from flexible filament (rubber)
- detailed build instructions in Czech and English depending on destination country (partial limited preview available below)
- the model can be further enhanced with a sound module, smoke generator etc.
- compatible with RC sets supporting OPEN TX or RC sets like HENG LONG and others
Recommended printing material: PLA (for static model), PETg, ABS, ASA, TPU/TPE (for rubber tires only), PC.
Build difficulty: 2/10
Dimensions (approximate):
- length: 63 cm
- width: 26.5 cm (with fenders)
- height: 21.5 cm
- weight: 3.6 kg (assembled model with basic electronics and gearboxes)
To complete the model, you will also need: 2)
- 4 kg of printing material see the publicly available guide below (PLA, PETg, ABS, ASA, TPU/TPE)
- 2 pcs 540-size 5-slot 20T motors, 11,700 RPM (@ 7.4 V)
- 2 pcs ESC (electronic speed controllers)
- 1–2 pcs 2S 7.4 V batteries
- RC set (at least 6 channels)
- 3 pcs mini servo MG90S 90°
- 1 pc mini servo MG90S 360°
- hex screws M2, M2.5, M3, M4
- nuts
- magnets
- brass threaded inserts
- bearings
- XL timing belts
- stainless steel wire, 1 mm diameter
- glue (cyanoacrylate, two-part epoxy)
The complete list of all required parts is available HERE.
Publicly available assembly guide (Czech version) can be viewed HERE.
Publicly available assembly guide (English version) can be viewed HERE.
Delivery time:
- usually immediate, but no later than 24 hours after payment
Notes:
* Model assembly requires precision and prior modeling experience.
* Only digital files for 3D printing are included.
* This model is not a replica or scale model of a real combat vehicle; therefore, some details or dimensions may differ from the original.
1) The design of the Jagdpanzer 38(t) Hetzer model emphasizes detail. However, it is not a replica or exact scale model of a real vehicle, so some details or dimensions may vary slightly from the real one.
2) See the publicly available guide linked in the product description.
